A PLC (Planar Lightwave Circuit) optical fiber cable splitter features: low insertion loss, excellent channel-to-channel uniformity, a wide operating wavelength range, compact design, high reliability and stability, and the ability to split an incoming optical signal into multiple equal outputs with minimal signal degradation; making it suitable for various fiber optic network applications where precise signal distribution is required.

Key features of a PLC splitter:

• Balanced power distribution:

   Evenly distributes the input optical signal across all output ports, ensuring each receiving device gets a consistent signal strength.

• Customizable split ratios:

  Can be manufactured with various split ratios (e.g., 1×2, 1×4, 1×8, etc.) to match specific network requirements.

• Wide operating wavelength:

  Operates across a broad range of wavelengths, allowing compatibility with different types of optical signals.

• Low polarization dependent loss (PDL):

  Minimizes signal loss based on the polarization of the light, ensuring consistent signal quality.

• Compact size:

  Offers a small footprint, ideal for dense network deployments.

• High stability:

  Resistant to environmental changes, providing reliable performance over time.

• Good channel-to-channel uniformity:

  Ensures consistent signal strength across all output ports.

Applications of PLC splitters

• Fiber To The Home (FTTH):

  Distributing optical signals to multiple homes from a single fiber optic cable.

• Gigabit Passive Optical Networks (GPON):

  Enabling high-speed data transmission to numerous users.

• Data Center Networks:

  Splitting optical signals for efficient network infrastructure.

• Video Surveillance Systems:

  Distributing video signals to multiple monitoring points.

• Function: Splits an optical signal from a single input fiber into multiple output fibers with a predetermined power distribution ratio.
• Technology: Based on Planar Lightwave Circuit (PLC) technology, using semiconductor manufacturing techniques to create the waveguide structure on a chip.
• Applications: Primarily used in Passive Optical Networks (PON) like GPON, EPON, and BPON to connect the main distribution frame (MDF) to individual user terminals.
• Split Ratios: Can be configured with various split ratios depending on the network requirements, such as 1×2, 1×4, 1×8, 1×16, or even higher.

Benefits:

• High channel-to-channel uniformity, meaning each output port receives a similar amount of power.

• Low insertion loss, minimizing signal degradation

• Compact size, suitable for high-density applications
